Spectral Purity 13.4
Spurious & Image Rejection (–20 dBFS into ADC, 0dB attn., max gain) typical:
SW Spur Reject 9 kHz to 1.5 GHz 1.5 GHz to 5.0 GHz 5.0 GHz to 6.0 GHz
Off -39 dBc -37 dBc -22 dBc
On -39 dBc -46 dBc -48 dBc
Phase noise at 1 GHz:
Frequency Offset dBc/Hz
100 Hz -70
1 kHz -78
10 kHz -84
100 kHz -96
1 MHz -116
LO Leakage: ≤ –65 dBm out the RF input connector
Timing 13.5
External Trigger: ±50 nS (4 samples)
GPS Synchronization: 1-PPS GPS precision time stamping
Accuracy: ±50 nS (4 samples) plus GPS error
Environmental 13.6
Operating Temperature: 32°F to 122°F (0°C to +50°C) without derating specifications
Typical internal temperature is 15°C above ambient. Internal temperature is not to exceed 70°C
while operating.
Size and Weight:
7.63” x 3.19” x 1.19” (194mm x 81mm x 30mm)
Net, 0.69 lb. (0.31 kg)
