Assembly Instruction Manual LabScat 2
12112E/2 19
Insert bottle centering device:
Insert the separately supplied bottle centering
device into the instrument and fasten with the
two knurled screws.
Position the water bath cover on the locking
pins (arrow positions) and press down until the
locks snap into place.
Fasten the drain hose on the drain tube (3)
with a hose clamp.
Fasten inlet hose on the inlet tube (2) with a
hose clamp.
The supplied water filter must be insert-
ed between the inlet and the water withdraw-
al. This protects the water bath and bottle cen-
tering device from dirt particles.
