Instruction Manual LabScat 2 Operation
32 12112E/2
7.8.2 Numerical entry
The following screen is for entering numbers and data:
Figure 10: Numerical entry

Parameter name

Entered values

Prefix: For entering very large or
very small values. This can be done
as follows:
1. Enter value
2. Select SI prefix
Function:
n = 10
-9
, u = 10
-6
, m = 10
-3
,
k = 10
3
, M = 10
6
, G = 10
9

Numerical entry

: Deletes one digit of the dis-
played value.
C: Clears the displayed value.
ESC: Touching the ESC field causes
the display to go back one level in
the menu hierarchy. The entered
value is not saved.
OK: Confirm entered value.

If the value entry is too high or too
low, a white arrow appears in a red
field top right.
Arrow points upward: Entry too high
Arrow points downward: Entry too
low
