Dimensions & Weight (unpacked)
MCU
435 mm (w) x 270 mm (h) x 85 mm (d). Weight: 3.1 Kg
Enclosure BF359/3D
725 mm (w) x 448 mm (h) x 193 mm (d). Weight 11.1 Kg
Type A Outstation EVC301RPO/RLK
202 mm (w) x 278 mm (h) x 100 mm (d). Weight: 3 Kg
Bezel T-BEZ301
244 mm (w) x 320 mm (h) x 20 mm (d). Weight: 0.5 Kg
Type B Outstation EVC302S/GS
160 mm (w) x 240 mm (h) x 53 mm (d). Weight: 1.3 Kg
Type B Outstation EVC302F/GF
175 mm (w) x 250 mm (h) x 53 mm (d). Weight: 1.5 Kg
Enclosure BF359/1
200 mm (w) x 302 mm (h) x 123 mm (d). Weight: 3.3 Kg
FiTT
77 mm (w) x 135 mm (h) x 35 mm (d). Weight: 0.16 Kg
SDM
48 mm (w) x 60 mm (h) x 30 mm (d). Weight: 0.003 Kg
