25
Starting up
EN
Threading the upper thread
For good sewing results, the threading must be carried out cor-
rectly. Otherwise several problems will occur.
1
ON
OFF
Thread the upper thread:
1. Set the main power switch (26) to the “I ON” position. Lift
the two-step presser foot lever (22).
2
2. Press the needle up/down position button (4) to bring the
needle and thread take-up lever (1) to highest position.
WARNING!
Turn the main power switch to “0 OFF“ position when carrying
out all the operations!
3
3. Slide the bobbin and the spool pin cap onto the horizontal
spool pin (19). For better sewing quality, choose a spool
pin cap (n) of a suitable size for the thread and attach it
next to the bobbin.
①
Large spool pin cap
②
Small spool pin cap
4
4. Pull the thread from the spool through the upper thread
guide (20).
NOTE
The needle threader can be used with home sewing machine
needle sizers from 75/11 to 100/16 .
To Next Page
