Silvus StreamCaster MIMO - Table 5 SC3822 Extension Connector Pinout; Table 4 SC3822 USB;GPIO Connector Pinout

StreamCaster MIMO Radio User Manual 3/17/15
10017C000 Silvus Technologies Confidential Page
13
Enclosure USP/GPIO
(LF10WBRB-12PD)
Signal
1
USB_GND
2
USB_D-
3
USB_5V
4
NC
5
GPIO1 (PA Enable 3.3V)
6
GPIO2
7
GPIO3
8
3.3V
9
GND
10
USB_Sense
11
USB_D+
12
GPIO4
Table 4 SC3822 USB/GPIO Connector Pinout
SC3822 Extension Connector Pinout
Pin #
Signal
Notes
1-6
VCC_IN
9V - 36V. These pins are directly wired to the VCC_IN on FPC 1.
7-10
GPIO1 – GPIO4
These GPIOs are directly wired to the GPIOs on FPC connector 2.
11-19
Reserved for Testing
Do Not Connect
20
CPU Reset (3.3V)
Wired to PS_SRST_EXT signal on FPC 1
21-54
Reserved for Testing
Do Not Connect
55
GND
56
ETH1_MX4N
Second Gigabit Ethernet Interface
57
ETH1_MX4P
58
ETH1_MX3N
59
ETH1_MX3P
60
ETH1_MX2N
61
ETH1_MX2P
62
ETH1_MX1N
63
ETH1_MX1P
64
GND
65-68
Reserved for Testing
Do Not Connect
Table 5 SC3822 Extension Connector Pinout
