Silvus StreamCaster MIMO - Serial Port Setup

StreamCaster MIMO Radio User Manual 3/17/15
10017C000 Silvus Technologies Confidential Page
33
NSS
MCS
Coding Rate
PHY Throughput
(Mbps)
UDP User Throughput
(Mbps)
SC3500/SC3800
Sensitivity
SC3822
Sensitivity
1
0
BPSK 1/2
3.25
2.48
-99
-96
1
1
QPSK 1/2
6.5
4.96
-97
-94
1
2
QPSK 3/4
9.75
7.40
-94
-91
1
3
16-QAM 1/2
13
9.90
-92
-89
1
4
16-QAM 3/4
19.5
14.80
-89
-86
1
5
64 QAM 2/3
26
19.90
-84
-82
1
6
64 QAM 3/4
29.25
22.40
-82
-80
1
7
64 QAM 5/6
32.5
24.0
-77
-78
2
8
BPSK 1/2
6.5
4.96
-97
-94
2
9
QPSK 1/2
13
9.90
-94
-91
2
10
QPSK 3/4
19.5
14.80
-91
-88
2
11
16-QAM 1/2
26
19.90
-89
-86
2
12
16-QAM 3/4
39
29.90
-85
-82
2
13
64 QAM 2/3
52
39.70
-81
-79
2
14
64 QAM 3/4
58.5
43.50
-79
-77
2
15
64 QAM 5/6
65
48.1
-74
-75
Table 11 MCS vs. Sensitivity Chart (10MHz Bandwidth)
NSS
MCS
Coding Rate
PHY Throughput
(Mbps)
UDP User Throughput
(Mbps)
SC3500/SC3800
Sensitivity
SC3822
Sensitivity
1
0
BPSK 1/2
6.5
4.92
-96
-93
1
1
QPSK 1/2
13
9.82
-94
-91
1
2
QPSK 3/4
19.5
14.73
-91
-88
1
3
16-QAM 1/2
26
19.65
-89
-86
1
4
16-QAM 3/4
39
29.47
-86
-83
1
5
64 QAM 2/3
52
39.29
-82
-79
1
6
64 QAM 3/4
58.5
44.20
-80
-77
1
7
64 QAM 5/6
65
47.45
-78
-75
2
8
BPSK 1/2
13
9.82
-94
-91
2
9
QPSK 1/2
26
19.65
-91
-88
2
10
QPSK 3/4
39
29.47
-88
-85
2
11
16-QAM 1/2
52
39.29
-86
-83
2
12
16-QAM 3/4
78
57.04
-82
-79
2
13
64 QAM 2/3
104
75.00
-79
-76
2
14
64 QAM 3/4
117
75.00 (85.00 for SC3822)
-77
-74
2
15
64 QAM 5/6
130
75.00 (85.00 for SC3822)
-75
-72
Table 12 MCS vs. Sensitivity Chart (20MHz Bandwidth)
