Simplex 4100+ User Manual

25
Figure 5 shows the cursor positioned on Item 1. To select Item 4 (Alarm Historical Log), move the cursor to Item 4
with the cursor control keys, or type the number <4> key and press the <ENTER> key.
Figure 5
CRT Main Menu Screen
ACKNOWLEDGE SCREEN
The entire 4100 system (including the CRT ports) is configured as either a Global Acknowledge system or as an
Individual Acknowledge system. If the system is configured as a Global Acknowledge system, one press of the
<PF1> key acknowledges all abnormal conditions that can be annunciated by the port. When the system is
configured as an Individual Acknowledge system, the Acknowledge key, <PF1>, must be pressed to acknowledge
each condition change.
All conditions which can be displayed at the CRT can be acknowledged at the CRT, provided that you have logged
in at a sufficient access level. A tone on the CRT sounds to indicate unacknowledged conditions. (The tone can be
silenced with the <PF1> key.) When an abnormal condition occurs, you must select the appropriate acknowledge
screen. The Header information on the screen indicates the number of abnormal conditions which can be
annunciated by the CRT, and not necessarily the total number of abnormal conditions in the system. To acknowledge
an abnormal condition, press the <PF1> key while in the acknowledge screen. The displayed condition will stop
flashing, but will still indicate the abnormal condition. When all abnormal conditions have been acknowledged, you
can return to the Main Menu by pressing the <F18> key.
As with the operator interface, alarms have priority over supervisory and trouble conditions. Multiple conditions are
displayed in chronological order. Should multiple unacknowledged conditions occur, no unacknowledged event is
allowed to scroll off the screen. If more unacknowledged conditions exist in the system than can fit on the screen,
the “oldest” unacknowledged point is displayed first. After that condition is acknowledged, it scrolls off the top of the
screen and is replaced by the next oldest condition.
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
TIME: 10:05:24 PM
DATE: MON 04 APR 94
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
SYSTEM IS NORMAL
- - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - -
4100 FIRE ALARM OPERATOR INTERFACE
MAIN MENU
1
. Alarms - Display any Current Alarms
2. Supervisories - Display any Current Supervisories
3. Troubles - Display any Current Troubles
4. Alarm Historical Log
5. Trouble Historical Log
6. System Functions
Select Option or PF1 to Acknowledge > 1
4100 F/A SYSTEM USER: 1
PORT 1 - SECURITY OFFICE ACCESS: 1
firealarmresources.com

Simplex 4100+ Specifications

General

Type	Addressable Fire Alarm Control Panel
SLC Loops	Up to 10
Operating Temperature	32°F to 120°F (0°C to 49°C)
Humidity Range	10% to 93% non-condensing
Display	LCD
Communication	Ethernet
Power Supply	120/240 VAC, 50/60 Hz
Battery Backup	24 VDC
NAC Outputs	Expandable
Releasing Capability	Yes, with releasing modules
Max Notification Appliance Circuits (NACs)	Varies by modules
Max Releasing Circuits	10
Communication Ports	Ethernet
Max Devices	3, 000
