53
The Service Report shown in Figure 33, as well as the Status Report shown in Figure 32, can either be displayed
on the remote CRT or captured permanently by using a remote printer. This information is available at the interface
panel LCD by identifying the specific point of interest and reading one point at a time.
GENERATING TrueAlarm
REPORTS
• Applies only to systems that feature a printer.
To Obtain a TrueAlarm
Status Report
1. Press the <MENU> key on the DISPLAY/ACTION keypad. Then press the <NEXT> key seven times.
• The alphanumeric display reads:
2. Press <ENTER>. Then press <NEXT> twice.
• The alphanumeric display reads:
3. Press <ENTER>.
• Printer prints out TrueAlarm
Status Report.
To Obtain a TrueAlarm
Service Report
1. Perform Step 1 above. Then press the <ENTER> key once and the <NEXT> key three times.
• The alphanumeric display reads:
2. Press <ENTER>.
• Printer prints out TrueAlarm
Service Report.
MAPNET II
ALPHANUMERIC DISPLAYS
When a MAPNET II
device changes to an abnormal state, or the operator enters a MAPNET II
device address,
the alphanumeric display shows the current status of the MAPNET II
device. After entering a MAPNET II
device
address, press the <FUNCTION> key on the interface panel to display additional device information.
For the TrueAlarm
sensor, device information reported back to the interface panel also includes data about the
condition of the sensor itself. For example, the sensor might report that it is dirty or excessively dirty.
Press <NEXT> or <PREVIOUS> to scroll
Print Reports?
Press <NEXT> or <PREVIOUS> to scroll
Report 3: TrueAlarm Status Report
Press <NEXT> or <PREVIOUS> to scroll
Report 4: TrueAlarm Service Report
To Next Page
