Simplex 4100+ User Manual

64
4. Using the ENTRY keypad, press the appropriate numeric key for the sensor’s channel (1 through 9, and 0),
the hyphen <–> key, and the appropriate numeric key(s) (1 through 127) for the sensor’s device number.
Then press the <ENTER> key.
• The display now shows you the location (custom label) and status of the sensor.
5. To verify the sensor’s MAPNET II

device address, press the <FUNCTION> key on the DISPLAY/ACTION
keypad. The display now looks like the example shown below.
• The channel and address displayed must match the address entered in Step 4.
NOTE: Pressing the <FUNCTION> key allows you to view status information on the sensor that was
verified in Step 5. Pressing the <FUNCTION> key or the <NEXT> key on the DISPLAY/ACTION
keypad repeatedly allows you to view 13 more status displays on this particular sensor; using the
<PREVIOUS> key allows you to go back and look at a previously viewed display.
Status displays 8 through 11 are explained below. The displays reveal the following information:
sensor’s sensitivity as programmed in the 4100 panel; average sensor value and sensor value
needed to cause an alarm; current sensor value; and highest (peak) sensor value to date.
6. To display the sensitivity programmed for the sensor, press the <FUNCTION> key six more times.
NOTE: If you accidentally press the <FUNCTION> key more than six times, you can go back one display
at a time using the <PREVIOUS> key on the DISPLAY/ACTION keypad.
• The display shows part of the custom label (location) along with the sensor’s present sensitivity.
7. Press the <FUNCTION> key again to display the sensor’s average and alarm value.
• The display shows sensor location, average sensor value, and sensor value needed to cause an alarm
condition.
• This display shows an average value of 90 for the last 2048 values reported by the sensor. It also shows
that a sensor value of 158 is needed to cause an alarm condition for the sensor.
8. Press the <FUNCTION> key again to display the sensor’s current value.
BLDG. 21-1 MECHANICAL ROOM
SMOKE DETECTOR NORMAL
DEVICE ADDRESS:1-15
MAPNET DEVICE:M1-15
BLDG. 21-1 MECHANICAL ROOM
PRESENT SENSITIVITY SELECTED = 2.5%SMOKE
BLDG. 21-1 MECHANICAL ROOM
AVERAGE VALUE = 90 / ALARM LEVEL = 158
