Technical specifications
Dimensions Refer to "Dimensional drawings" on
page 47
Weight (without accessories) 0.51 kg (1.13 lbs)
Power
Supply voltage 12 V (10.8V < supply voltage <
15.6V)
Supply connection Micro-C (CAN)
Backlight OFF 1.62 W (0.12 A @13.5 V)
Backlight MAX 2.97 W (0.22 A @13.5 V)
Network load 5 LEN (244 mA max)
Color Black
Display
Size 4.1" (diagonal). 4:3 Aspect ratio
Type Transmissive TFT-LCD
Resolution 320 x 240 pixels
Viewing angles 80° top/bottom, 80° left/right
Brightness > 600 nits
Color scheme White or black for day mode.
Red, green, blue or white for
night mode
Multiple controller support Yes
Mounting options Dashboard, bracket (sold
separately)
SW upgrade method USB
Alarm sound pressure level 75 dB
Environmental protection
Waterproof rating IPx7
Humidity 100% RH
Temperature
Operating -25°C to +65ºC (-13°F to +149ºF)
9
Technical specifications| AP™ 48 Operator Manual
45
