Simrad AP48 User Manual

Dimensional drawings
AP48 without bracket
177.0 mm
(6.97")
56.1 mm
(2.21")
23.1 mm
(0.91")
33.0 mm
(1.30")
55.4 mm
(2.18")
115.0 mm
(4.53")
AP48 with bracket
204.8 mm
(8.06”)
56
.1 mm
(2.21")
55.4 mm
(2.18")
84.6 mm
(3.33")
124.5 mm
(4.90")
10
Dimensional drawings| AP™ 48 Operator Manual
