Miscellaneous menu Chapter 7-11

7.7 SDGPS information

The SDGPS - satellite differential GPS - is preset to full automatic

operation, which means that the system will utilize the position cor-

rections from either differential GPS stations (refer to section 7.6)

or satellite differential GPS signals from WAAS, EGNOS or MSAS

(refer to section 7.7.1).

Call up the menu bar, and...

5,7

load SDGPS setup display

SDGPS setup:

SDGPS select mode: PASSIVE

Uses corrections from: *****

CHANNEL 1: sat.no.: **** ****

Corrections: NONE

Integrity messages ok: NO

Range used for position fix: NO

Type 0 warning received: NO

CHANNEL 2: sat.no.: **** ****

Corrections: NONE

Integrity messages ok: NO

Range used for position fix: NO

Type 0 warning received: NO

Ignore type 0 warnings: NO

ADJ

Open for change

Go to the function you wish to alter (see below)

+/-

Toggle the function

ENT

Confirm entry

SDGPS select mode determines which differential corrections can

be used in the position determination:

AUTO mode: Local area DGPS corrections are used when available.

If not available, then SDGPS corrections are used (if these are avail-

able).

PASSI V E mode: SDGPS corrections are never used (see section

7.7.1).

MANUAL mode: SDGPS corrections are used (if available). Local

area DGPS corrections are not used.

CX34/44/54 Operator manual
