Simrad CX34 User Manual

Chapter 2-6 Fundamentals & initial start-up
2.4 Menu layout
1
RADAR
2
CHART
3
ECHO
1
Radar
1
Chart
1
50kHz*
2
Dual Radar
2
Dual Chart
2
200kHz*
3
Radar & Chart
3
Custom screen 1
3
Dual Frequency (CX44/54)*
4
Custom screen
4
Custom screen 2
4
Depth & temperature diagram
5
Custom screen 1
6
Custom screen 2*
4
PILOT
5
MISC
6
WP/RTE
1
Highway
1
Wind
1
Waypoints
2
Position
2
Speed diagram
2
Routes
3
Dual Speed
3
Decca lanes
3
Route calculation
4
ETA & AVN
4
Loran C
4
Lines
5
Trim & Highway
5
Satellites
5
Tracks
6
Set & Drift
6
DGPS
6
Targets
7
Custom screen 1
7
SDGPS
7
MOB data
8
Custom screen 2
8
DSC info
8
Data transfer
7
SETUP
When selecting a sub-
menu in the SETUP
menu, the display
will always appear in
a pop-up window, so
once you have accepted
the changes / exit the
display, then the display
will disappear from the
screen.
RADAR
Radar setup
2
Interface setup
CHART
C-MAP cartridge
3
Palette setup
ECHO
Echosounder setup*
4
Factory settings
PILOT
Pilot/Position setup
5
QuickGuide
1
Speed alarm, units & language
*) available with built-in echosounder function.
CX34/44/54 Operator manual
