Chart menu and INFO windows Chapter 4-17
4.5 Chart setup
The settings are dedicated to the chart in the active window and does
not affect the second chart.
The C-MAP features available in the
chart setup will depend on the type of C-card used i.e. NT MAX (all
featues) or NT+ (refer to section 4.5.2 and Appendix C).
See section
3.2.7 for chart settings related to the RadarChart overlay.
ADJ
Load chart setup related to active chart
◄
GOTO
Presentation Dep
PLOT
►
Display mode FULL
Orientation NORTH UP
Rotation resolution 15°
Motion RELATIVE
Quick chart info ON
Cursor 5 min.time-limit ON
Auto chart select ON
Extended level range OFF
Show range WITH BACKGROUND
Tidal currents ICON
Value added data ON
Human dictionary ON
Grid AUTO
Boundary lines AUTO
Mixing levels OFF
Declutter ON
MENU
Exit Accept
ENT
The tabs indicate which groups are available in each display mode e.g.
the above example shows that in FULL display mode you have access
to the groups in black: General, Areas and User data. The two groups
in red i.e. Presentation and Depth are only adjustable in
CUSTOM
display mode. See further on in this chapter for more details.
+/-
Select display mode: FULL, CUSTOM, SIMPLE, FISHING, LOW,
GRID
∆
∆
General
CX34/44/54 Operator manual
