Simrad CX34 User Manual

Chapter 9-2 Setup menu
Example of Radar setup:
HU
RM
0.50nm
Head-Up in Relative Motion
Range= 0.50nm
Power off
Power off, X-MIT
TI 0
Tuning Indicator
Tune 100
*Tune, Gain, Sea: adjust with +/- keys, and press
[CLR] to return to AUTOmatic mode.
Gain 44
Sea 30
Rain 0
*Rain Clutter / FTC
Scanner type Auto
/Demo
Scanner height 05m
5 meters above water
Heading adjust 000.0°
*In degrees to ship’s center line
Tuning reference 079
*Adjust with +/-/numeric keys
Zero range/timing 0109
*Adjust with +/-/numeric keys
MBS 050 050
Main Bang Suppression, level and length (area)
Sensitivity 048
*Adjust with +/-/numeric keys
GZ target threshold 5
*Levels of 1 to 7
Power-on time 000000 h
Elapsed power-on time
Transmit time 000000 h
Elapsed transmission time
*Sea Auto, Sea Harbor and Gain Auto are preset
for best performance under normal conditions.
For technicians only.
Sea Auto 025 050 090
Sea Harbor 000 025 030
Gain Auto 020 082 040
Scanner status Activate
*= only adjustable in X-MIT mode.
More details on next pages.
Scanner type: is preset to Auto detect. After having installed the
scanner (see the Installation manual for selection of scanner), the
radar function must stay in Power off mode until the scanner type
is detected. The system will automatically set up the correct param-
eters for the connected scanner.
 Demo mode – see section 3.3.
Scanner height: enter the actual height above water of the radar
antenna/scanner.
Heading adjust: Orientation should be HU (Head-Up). Turn the
ship, so a target is just in front and adjust until target is straight
ahead on the heading line. Use the +/- keys to position it correctly.
AUTO
AUTO
AUTO
CX34/44/54 Operator manual
