EQ42/50/52 SETUP menu Chapter 7
35
Interface setup: OUTPUT
Port: NMEA1 – NMEA0183. NMEA2 – NMEA0183
Sentence String NMEA1 NMEA2
Water data:
Water temperature: MTW ON ON
Water speed and heading: VHW ON ON
Depth below keel: DBK OFF OFF
Depth below surface: DBS OFF OFF
Depth below transducer: DBK OFF OFF
Depth: DPT ON ON
Waypoint data:
Waypoint location: WPL ON ON
MENU
Exit Accept
ENT
7.3 Interface setup, Alarm output (for external alarm relays)
MENU
Call up the menu bar, and…
5,3
press
[5]
and
[3]
to call up the interface setup display for alarm
Interface setup, alarm:
Output (pin 1,2):
Alarm stand-by level:
ON
LOW
Alarm stand-by level can be LOW = 0 volt, or HIGH = 5 volt.
Use the cursor to move around in the display
+/-
Toggle between available values
ENT
Confirm entry, or…
MENU
exit function without making any changes
