EQ42/50/52 Navigation menu Chapter 4
17
4. Navigation menu
_2_
NAV
_1_ Highway
4.1 Highway display
MENU
Call up the menu bar, and…
2, 1
load highway display
To present any information in the EQXX highway display will require
that a navigator is connected via the NMEA input port.
) The connected navigator must be in a navigation mode, which could
be Cursor, Waypoint, Route or Track navigation. See next page.
4.2 Navigation setup
ENT
The navigation setup display is accessed by pressing [ENT] from the
navigation display:
Navigation setup:
XTE distance: 00.50nm
Alarm distance can be changed in this display, but alarm can only be
initiated from the connected navigator. Maximum setting in nautical
miles is 9.99 nm.
ENT
Return to the highway display
