EQ42/50/52 Installation and service Chapter 9
56
9.6.1 Power supply connections
The internal voltage regulator will allow the EQXX to operate normally over the
power supply voltage range from 10 to 32 V dc. Connections between the EQXX
and the external power supply are accomplished by means of the supplied power
cable, which is approximately 1.5 meters long.
After connecting the cable to the power source, push the plug as far as it will go
into the two pin receptacle marked “PWR” on the rear of the cabinet and turn the
plug’s coupling ring clockwise until it clicks into locked position.
9.6.2 Fuse
Warning! Using a fuse which is not specified for your equipment can cause it to
blow the instant the EQXX has been switched on or it will not protect the
equipment in the event of trouble. Refer to 9.11 Specifications.
9.6.3 Transducer connection
Most transducers are supplied with a 10 meter cable for connection to the
echosounder unit – EQXX.Pushthefemaleplug,asfarasitgoes,intothe
receptacle marked “ECHO1” or/and “ECHO2” on the rear of the cabinet and turn
the plug’s coupling ring clockwise until it clicks into locked position
) The EQXX must be turned off while connecting/disconnecting the transducer
cables.
Recommended connection and setup of Simrad supplied transducers:
Transducer type Port Echosounder setup
Simrad 50/200 C ECHO2 Simrad Combi C50/200
Simrad 38/200 C ECHO2 Simrad Combi C38/200
Airmar B250 ECHO2 Airmar Combi B250-22
Airmar B260 ECHO2 Airmar Combi B250-22
Airmar P319, P52, P66,
B117, B45, SS505,
B744V, SS544V, B256
ECHO1 200kHz Airmar Des. A
50kHz Airmar Des. A
Airmar ST650 ECHO1
) See transducer connections next page, and Echosounder setup, section 5.7.
