Simrad EQ42 - 9.2 Installation of EQ50 Echosounder

EQ42/50/52 Installation and service Chapter 9
49
9.2 Installation of EQ50 Echosounder
The EQ50 can be flat or bracket mounted – overhead*, bulkhead* or console.
* Overhead and bulkhead mounting
is only possible if using a distance
piece.
295 (11.6)
74 (2.9)
116 (4.6)
376 (14.8)
419 (16.5)
445 (17.5)
9(0.4)
20 (0.8)
196 (7.7)
75 (3.0)
