GN33
GN33
Unit #1
Unit #2
Blue/white dot
Blue/yellow dot
Purple/black
Blue/yellow dot
Blue/white dot
Not usable
Purple/black
← 2 m →
Alarm/data cable
153-6070-001
GN33 Installation and service Chapter 10-9
10.6.2 Data transfer between two GN33 units
A second GN33 can be connected via the REMOTE port to enable exchange
of waypoint and route data. For interconnecting two GN33 units, use two
alarm/data cables, part no. 153-6070-001.
