Chapter 1-2 GN33 Introduction and safety summary
How to interpret special marked key symbols etc. in the manual:
+/-
Either the + (plus) or - (minus) key may be applied.
0-9
Alpha-numeric keys for insertion of figures.
A-Z
Alpha-numeric keys for insertion of letters.
Emphasizes important points.
1,3
Indicates that you should press the keys [1] and [3] to obtain what is
written in italic next to the key.
1.2 Safety summary
Precaution: Do not open the equipment, only qualified persons should work
inside the equipment. If the glass in the screen breaks, be carefull not to get
cut on the sharp edges of the glass pieces.
The lifetime of the internal battery is minimum 5 years. If not exchanged
before it goes flat, all data in the unit’s memory will be lost. We strongly
recommend that you bring in the GN33 unit to a Simrad workshop for a new
battery max. 5 years from date of purchase.
Power source, fuse and power cable: Check that the DC power supplied to
the unit is within the range of 10 to 32 volts. Note that the appropriate fuse
must be employed (see the fuse rating in section 10.10 Specifications). Ensure
that the power cord is firmly attached.
Grounding: To reduce electrical interference and risk of electrical shock,
properly ground the unit to the ship’s ground using the ground screw at the
rear of the unit. Good grounding should also be exercised for equipment con-
nected to the GN33.
Cleaning:
Do not use any kind of strong solvents e.g. spirit, alcohol, gasoline or oils.
1.3 How to get started
PWR
Press and hold the [PWR] key until you have a picture on the screen
ENT
Press the [ENT] key to accept warning when the system is ready
Your present position will automatically be updated within a few minutes.
