GN33 Fundamentals & initial start-up Chapter 2-5
The menu bar will disappear from the screen at the selection of a
function, or by pressing the [MENU] key. Besides, if not used, it
automatically turns off after 30 seconds.
2.4 Menu layout
1
CHART
2
POS
3
WP/RTE
1
Chart 1 1:26400000
1
Position
1
WP list
2
Chart 2 1:6600000
2
Dual speed
2
Routes
3
C-MAP cartridge
3
Speed, course & depth
3
Route calculation
4
Speed diagram
4
Lines
5
Satellites
5
Start track
6
DGPS
6
Stop track
7
SDGPS
7
Tracks
8
Targets
4
PILOT
5
ECHO
6
MISC
1
Highway
1
Depth & temperature diagram
1
Wind
2
Waypoint navigation
2
MOB position
3
Route navigation
3
DSC alarm
4
Track navigation
4
Data transfer
5
Anchor guard
6
Trim & highway
7
Set & drift
The PILOT menu is dynamic and will adapt to the function which is
currently active - see next page.
To Next Page
