Maintenance
Preventive maintenance
The unit does not contain any field serviceable components. Therefore, the operator is
required to perform only a very limited amount of preventative maintenance.
It is recommended that you always fit the supplied protective sun cover when the unit is not
in use.
Checking the connectors
The connectors should be checked by visual inspection only.
Push the connector plugs into the connector. If the connector plugs are equipped with a
lock, ensure that it is in the correct position.
NMEA Data logging
All serial output sentences sent over the NMEA TCP connection are logged to an internal file.
You can export and review this file for service and fault finding purposes.
The maximum file size is predefined. If you have added several other files to the system (file
recordings, music, pictures, PDF files), this may reduce the allowed file size for the log file.
The system logs as much data as possible within the file size limitation, and then it starts
overwriting the oldest data.
Exporting the log file
The log file can be exported from the files dialog.
When you select the Log database you are prompted to select a destination folder and
filename. Once accepted, the log file is written to the chosen location.
RSD sentence output
The output of RSD NMEA 0183 message can be enabled (default off) to provide cursor
position information to an external device. The cursor position information may be used by
devices such as thermal cameras with pan-tilt ability, and external radar displays.
24
126
Maintenance| NSO evo2 Operator Manual
