The FLIR camera is controlled from the Video panel, and no additional icons appear on the
Home page.
Refer to "Video" on page 117 for more information.
BEP CZone integration
The NSO evo2 integrates with BEP’s CZone system used for controlling and monitoring a
distributed power system on your vessel.
The CZone icon is available in the Tools panel on the Home page when a CZone system is
available on the network.
A separate manual is provided with your CZone system. Refer to this documentation and to
the NSO evo2 Installation manual for how to install and configure the CZone system.
CZone dashboard
When the CZone is installed and configured, an additional CZone dashboard is added to the
Instruments panels.
Vessel dashboard Navigation dashboard Angler dashboard CZone dashboard
You switch between a panel’s dashboards by selecting the left and right arrow symbols or by
selecting the dashboard from the menu.
Editing a CZone dashboard
You can customize a CZone dashboard by changing the data for each of the gauges.
Available editing options depend on the type of gauge and which data sources that are
connected to your system.
For more information, refer to "Instrument panels" on page 105.
16
Introduction | NSO evo2 Operator Manual
