Alert icons
The table shows the alert icons depending on if the alert is active,
acknowledged or rectified.
Alert type Icon State
Warning
Active - not acknowledged, not
silenced
Active - not acknowledged, silenced
Active - acknowledged
Rectified - not acknowledged
Caution Active
AIS target symbols
Sleeping AIS target (not moving or at anchor).
Moving and safe AIS target with course extension line.
Dangerous AIS target, illustrated with bold line.
A target is defined as dangerous based on the CPA and
TCPA settings.
Lost AIS target.
When no signals have been received within a time
limit, a target is defined as lost.
The target symbol represents the last valid position of
the target before the reception of data was lost.
Appendix | P2005/P3007 Operator Manual
59
