46 |
Operation | V5035 Operator and Installation Manual
AIS TARGET LIST MMSI
2013/01/17 23:27:10
Dangerous Targets :0 IL
[001]-NAME/MMSI--ET-BRG( °)-RNG(KM)
1. TEST01 3s 90 15.09
CREATE ETA REPORT
2013/01/17 23:27:10
DESTINATION MMSI [200000001]
TX CHANNEL
<
ALTERNATE
>
Fairway Number [ABCDE]
UN Country [UK]
ETA [12/24 13:50]
Fairway Hectometre [LMINO]
Num Of TugBoat [6]
Terminal Code [FGHIJK]
UN Locaon [BTG]
Air Draught (m) [10.99 m]
IL
--------------- ETA INFORMATION ---------------
Dangerous Targets :0
Target selection and ETA report
Use the knob to select a message and press the knob to display
message content.
POB Outbox
The submenu displays log of sent Number of person on board
(RFM55/IFM16) messages. The IMO version sends the total number
of persons on board as a binary message with international IFM16.
The Inland (IWW) version sends a message with number of crew,
personnel and passengers as a binary message with inland branch
RFM55.
POB OUTBOX
2013/01/17 23:27:10
Targets Received :1 IL
---DEST. MMSI -- TYPE -- DATE/TIME---- TX
1. 200000001 RFM55 T 17:43 YES
MESSAGE INFORMATION
2013/01/17 23:27:10
Sour. MMSI 211000001
DEST. MMSI 200000001
TIME 2013/07/03 17:43:59
CREW MEMBERS [200]
TX OK YES
RX ACK YES
SHIPBOARD PERSONNEL [200]
PASSENGERS [1000]
IL
ABK INFO Late received by the Dest.AIS
TX TYPE Addressed
Targets Received :1
POB outbox and POB message information
Use the knob to select a message and press the knob to display
message content.
Create POB message
In this submenu users can compose number of person on board
(RFM55/IFM16) messages. Number of person onboard can be con-
figured in Inland Setting 0.
By entering into the submenu, users will be prompted to select the
addressee from the target list. Here you can either pick the address-
ee from the list or press ESC to leave the target list to enter the MMSI
number manually or broadcast the POB message without specifying
any addressee.
