3.5.2 4-Way remote key control
Pressing a key on the NavPad has the same effect as pressing a
specified key on the device being controlled and may be
considered a Remote Key Press.
3.5.3 8-Way Remote Control Mode
In this mode, combination keys are allowed. For example, pressing
V
and
W
together will be interpreted as diagonally up and to the
left. This can be useful for positioning the cursor on a Chartplotter
or Radar if connected into the SimNet Network.
3.6
MENU key (Enter/menu key)
The
MENU key (Fig. 3.1 Item 7), has two functions :
3.6.1 Menu function
Pressing the
M
ENU key will bring up the menu associated with
the product that is currently selected on the WR20.
3.6.2 Enter function
When navigating within a menu, once an item has been highlighted,
pressing the
M
ENU key will select that item; this could be
another menu, data item to adjust, or a new product to control.
3.7 Product key
Pressing the PRODUCT key (Fig. 4.1 Item 6), brings up the top level
display showing all products that are available for control by the
WR20.
3.8 STBY/Auto key
The STBY/AUTO key (Fig. 4.1 Item 9), is exclusively reserved for
the Autopilot and will only be usable if there is a WR20
compatible Autopilot connected to the Network.
If the WR20 is controlling any other product, a single press of the
S
TBY/AUTO key will put the Autopilot into standby mode and give
the WR20 Handset the active control (See section 6.3)
Press and holding the S
TBY/AUTO key for 2 seconds will put the
Autopilot into Auto Compass mode and give the WR20 Handset
the active control (See section 6.5).
Handset & Keypad Overview
19
Handset &
Keypad Overview
