The selected instrument will show “CTRL” flashing briefly in its
display.
The text legend shown on the keys in the WR20 display will
emulate the keys of the selected instrument.
For information on the functionality of each instruments keys,
please refer to the relevant instrument user manual.
Note When remotely controlling an instrument from the WR20, the result
of a key press can be seen in that selected instrument and not in
the WR20 display.
Note To select a different instrument press
MENU key and select from
the list.
WR20 Remote Commander
52
Instruments
Fig. 9.2 - Depth Instrument
fpNOJMM=
=
abmqe
LIGHT
SHALL
INFO
DEEP
H
