5-23
Maintenance
5
1 Remove Snap-Ring.
SNAP-RING
2 Press the tube holder and pull the tube to remove.
TUBE
TUBE HOLDER
3 Push the top of the front handle, and lift it up to open the cover.
HOOK
COVER
