4 Pull the nozzle component to detach.
NOZZLE
Assembling the Nozzle
Initiate process ONLY after power of machine is turned OFF, and after all power cables are disconnected.
1 With the cover lifted up attach the nozzle.
The magnet of the nozzle attaches to the surface, but check if it is fully attached by shaking it. Also, inspectthe
spring pin and see if it is connected properly.
Note
-
If the spring pin is not connected properly, the nozzle may malfunction.
NOZZLE
2 Push the cover down and make sure to hear the clicking sound.
COVER
