4 Slightly lifting the tube and insert the Snap-Ring.
Insert the Snap-Ring in between the Fitting and Holder.
SNAP-RING
SNAP-RING
INSERTION
POINT
5 Finally, push tube in all the way through.
-
Approximately 1.5mm can be additionally inserted.
TUBE
6 Use the [Cartridge] – [(Select a cartridge to load)] – [Cartridge to load] command to finish the cartridge
loading process.
