Singer 9985 - Top Cover (Flap); Base

SERVICE MANUAL
13
B. Base
1. Tilt the machine backward.
2. Connect the connector so that the hook (d) will fit into
place.
3. Replace the base and retighten the 3 screws.
C. Top Cover (Flap)
1. Slide the top cover to the left so that the hook (b) will
fit onto the pin of unit cover.
2. Pull the right side of top cover and snap on the hook
(a) onto the pin of unit cover.
1
2
b
a
3
2
d
