Singer 9985 - Top Cover (Flap); Hinge Cover; Thread Tension Cover

SERVICE MANUAL
4
C. Top Cover (Flap)
1. Open the top cover.
2. Push the right side of top cover backward and remove
the hinge (a).
D. Hinge Cover
1. Insert the tip of screw driver and pull up the front side
of hige cover.
E. Thread Tension Cover
1. Remove the screw (a).
3. Slide the top cover to the right and remove the hinge
(b).
2. Push the Thread tension cover backward ; 2 hooks (b,
c) will come off.
3. Pull up the cover.
2
a
3
b
1
1
2
a
b
c
