Singer 9985 - Needle Plate

SERVICE MANUAL
6
H. Needle Plate
1. Remove the presser foot and holder.
2. Remove the 2 screws (a, b) holding the needle plate.
4. Next, push the left side of unit cover backward and
pull up it to come off from the thread guide cover.
4
5. Slide the handle and unit cover to the left and remove
them.
5
2
a
b
3. Lift up the right side of needle plate and remove it.
3
