Singer SE300 - Threading the Machine; Bobbin Setting and Winding Procedures; Setting the Spool of Thread

17
SETTING UP THE MACHINE
BOBBIN SETTING
Be sure to use only SINGER Class 15 bobbins (transparent) in
this machine.
removIng the bobbIn
1. Pull the bobbin cover latch to the right and remove the
bobbin cover.
2. Lift up the bobbin from the machine.
threadIng the machIne
SettIng Spool of thread on Spool pIn
1. Pull up the left end of spool pin and set the felt washer and
the spool of thread on spool pin so that the thread unrolls
from the front of the spool.
2. Set the spool cap on spool pin as far as it will go.
a. Reverse spool cap direction according to the size of
spool.
b. Use the small spool cap when you use cross wound
thread. Leave small opening between cap and spool as
illustrated.
c. Set the thread net over the spool if thread unrolls too
easily.
wIndIng the bobbIn
1. Hold thread in both hands and hook thread to the guide
from front opening.
2. Bring thread to the right and pass it through the thread
guide from the back side. Pass thread under the bobbin
winding tension disk in a clockwise direction.
3. Insert thread through hole in bobbin and place the bobbin
on bobbin winder spindle.
4. Hold the end of the thread and push bobbin stopper to the
right. When the bobbin winding screen appears, press the
Start/Stop button on the screen to start winding.
5. After the bobbin winds a few turns, stop the machine by
pressing the Start/Stop button on the screen.
6. Cut the thread near the hole, as illustrated.
7. Start the machine again by pressing the Start/Stop button
on screen. You can adjust winding speed by pressing “+”
(faster) or “-” (slower) button on the screen.
8. When the bobbin is wound fully, the bobbin stopper will
return to the left and stop winding automatically.
9. Remove the bobbin from the spindle and cut thread with
the thread cutter.
