MACHINE SPECIFICATIONS
1323RD&1623RD Operation Manual 1-5 © Mar. 2022
Table 1-2 1623RD specifications (continued)
MEASURE
1623RD (METRIC) 5389RD (IMPERIAL)
Max. allowable altitude 1000m 3280.8ft
Allowable ambient temperature
(lead-acid batteries)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium batteries)
-20℃～40℃ -4℉～104℉
Max. allowable ambient relative
humidity
90%
Storage condition
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment
with 90% relative humidity (20℃ [68℉]), and away from rain, sun,
corrosive gas, inflammables and explosives.
WEIGHT
Total weight 8780 kg
19357 lb
NOTE:
a) The platform height plus the operator height (taken as 2m [6ft 7in]) is the working height.
b) In different areas, hydraulic oil, engine oil, coolant, fuel and lubricant should be added in accordance with the
environmental temperature.
c) In cold weather, auxiliary devices are needed to start the machines.
d) The ground bearing data is approximate, not considering different options and only applicable when it is safe
enough.
e) The loads of persons, accessories, tools and materials are factored into the rated platform capacity.
f) The total vibration value of the platform does not exceed 2.5m/s², and the maximum root-mean-square value of
the weighted acceleration of the entire machine does not exceed 0.5m/s².
g) The hydraulic tank capacity is the maximum volume in the hydraulic tank.
