1323RD&1623RD Operation Manual 1-1 © Mar. 2022
1 MACHINE SPECIFICATIONS
Table 1-1 1323RD specifications
MEASURE
1323RD (METRIC) 4389RD (IMPERIAL)
DIMENSIONS
Max. platform height
13.1 m 42ft 11.7in
Max. working height
15.1 m 49ft 6.5in
Max. horizontal reach (rear
extension platform extended)
1.2 m 3ft 11.2in
Max. horizontal reach (front
extension platform extended)
1.5 m 4ft 11.1in
Overall length
4.88 m 16ft
Overall width 2.28 m 7ft 5.7in
Overall height (stowed, rails folded)
2.22 m
7ft 3.4in
Overall height (stowed, rails up)
2.98 m 9ft 9.3in
Wheelbase 2.84 m 9ft 3.8in
Wheel span
1.95 m 6ft 4.7in
Ground clearance 0.36 m 1ft 2.2in
Tire size (diameter × width / type)
33×12-20/solid 315/55D20/foam-filled
Platform dimension (Length × Width
× Height)-6.5 m Platform
3.96 m×1.82 m×1.1 m 13ft×6ft×3ft 7in
Platform dimension (Length × Width
× Height)-7.4 m Platform
4.84 m×1.82 m×1.1 m 15ft 10.6in×6ft×3ft 7in
PERFORMANCE
Rated platform capacity 680 kg
1499 lb
Individual extension platform
capacity
227 kg
500 lb
Max. platform occupancy 7 persons
Drive speed (stowed)
0～6.1 km/h
0～3.8 mph
Drive speed (raised)
0～1.1 km/h
0～0.68 mph
Up time (no load)
40～50 s
Down time (no load)
34～44 s
Gradeability 50% (26.6°)
Max. allowable inclination (front-to-
back)
3°
