© Mar. 2022 1-2 1323RD&1623RD Operation Manual
MACHINE SPECIFICATIONS
Table 1-1 1323RD specifications (continued)
MEASURE
1323RD (METRIC) 4389RD (IMPERIAL)
Max. allowable inclination (side-to-
side, outrigger retracted/extended)
2°/0.8°
Max. outrigger leveling angle (front-
to-back)
7°
Max. outrigger leveling angle (side-
to-side)
12°
Turning radius (inside)
2.2 m 7ft 2.6in
Turning radius (outside)
5.3 m 17ft 4.7in
Max. allowable side force 400 N 90 lbf
Max. operating noise 86 dB
POWER
Drive mode (drive×steer) 4WD×2WS
Engine (rated power, RPM)
36.3 kW, 2800 rpm (Deutz D2011 L03i)
35.5 kW, 3000 rpm (Yanmar 4TNV88C-DFLT)
36.4kW, 3000 rpm (Yanmar 4TNV88-BDFLTC)
35.3kW, 3000 rpm (Yanmar 4TNV88-ZCDCSI)
Fuel tank capacity 110 L 24 gal (UK)/29 gal (US)
Hydraulic tank capacity 140 L 30.8 gal (UK)/37 gal (US)
Hydraulic system pressure
24 MPa
3481 psi
Battery specification (voltage,
capacity, rate of discharge)
12 V, 110 Ah, 5 hr
Power system voltage
12 VDC
System control voltage 12 VDC
GROUND BEARING INFORMATION
Max. tire load
3900 kg
8598 lb
Tire contact pressure
720 kPa
104 psi
Max. outrigger load 3200 kg
7055 lb
Outrigger contact pressure
630 kPa
91 psi
ENVIRONMENT
Max. allowable wind speed (indoor)
0 m/s
0 mph
Max. allowable wind speed
(outdoor)
12.5 m/s 28 mph
Max. allowable altitude 1000m 3280.8ft
Allowable ambient temperature
(lead-acid batteries)
-10℃～40℃ 14℉～104℉
Allowable ambient temperature (-
lithium batteries)
-20℃～40℃ -4℉～104℉
