MACHINE SPECIFICATIONS
1323RD&1623RD Operation Manual 1-3 © Mar. 2022
Table 1-1 1323RD specifications (continued)
MEASURE
1323RD (METRIC) 4389RD (IMPERIAL)
Max. allowable ambient relative
humidity
90%
Storage condition
Stored at -20℃ to 50℃ (-4℉ to 122℉) in a well-ventilated environment
with 90% relative humidity (20℃ [68℉]), and away from rain, sun,
corrosive gas, inflammables and explosives.
WEIGHT
Total weight 7700 kg
16976 lb
Table 1-2 1623RD specifications
MEASURE
1623RD (METRIC) 5389RD (IMPERIAL)
DIMENSIONS
Max. platform height
16.2 m 53ft 1.8in
Max. working height
18.2 m 59ft 8.5in
Max. horizontal reach (rear
extension platform extended)
1.2 m 3ft 11.2in
Max. horizontal reach (front
extension platform extended)
1.5 m 4ft 11.1in
Overall length
4.88 m 16ft
Overall width 2.28 m 7ft 5.7in
Overall height (stowed, rails folded)
2.44 m 8ft
Overall height (stowed, rails up)
3.21 m 10ft 6.3in
Wheelbase 2.84 m 9ft 3.8in
Wheel span
1.95 m 6ft 4.7in
Ground clearance 0.36 m 1ft 2.2in
Tire size (diameter × width / type)
33×12-20/solid 315/55D20/foam-filled
Platform dimension (Length × Width
× Height)-6.5 m Platform
3.96 m×1.82 m×1.1 m 13ft×6ft×3ft 7in
Platform dimension (Length × Width
× Height)-7.4 m Platform
4.84 m×1.82 m×1.1 m 15ft 10.6in×6ft×3ft 7in
PERFORMANCE
Rated platform capacity 680 kg
1499 lb
Individual extension platform
capacity
227 kg
500 lb
Max. platform occupancy 4 persons
Drive speed (stowed)
0～6.1 km/h
0～3.8 mph
Drive speed (raised)
0～1.1 km/h
0～0.68 mph
