PRE-OPERATION FUNCTION TEST
1323RD&1623RD Operation Manual 6-17 © Mar. 2022
6. Shut off the engine.
7. Press simultaneously the both emergency lowering
switches.
8. The platform should lower until properly in place,
and the alarm should sound while the platform is
lowering.
TESTING THE LEVEL
SENSOR
UNSAFE OPERATION HAZARDS
• Don’t put your hands and arms
close to positions where they may
get squeezed.
• If the safety arm is not in the
proper position, don’t work under
the platform or near the scissor
arm.
NOTICE
Do not stand on the platform but on the ground using
the platform controller to perform this test.
1. Position the machine on a level, firm surface. Start
the machine, and the green indicator light on the
level sensor should illuminate.
2. With the machine in stowed position, place 2
wooden blocks near the two front or rear wheels,
then drive the machine upon the wooden blocks.
The wooden block dimension (L×W×H) is
100×50×150mm (4in×2in×5.9in).
3. Switch from drive to platform lift function, and raise
the platform until the lower limit switch disengages,
the red indicator light on the level sensor will
illuminate with the alarm sounding, and further
lifting and driving is restricted.
4. Lower the platform to the stowed position, the alarm
will stop sounding, and the machine function limit is
cancelled.
5. Drive the machine off and remove the wooden
blocks.
6. With the machine in stowed position (outrigger
retracted), place 2 wooden blocks near the two
wheels on the left or right side, then drive the
machine upon the wooden blocks. The wooden
block dimension (L×W×H) is 100×50×70mm
(4in×2in×2.76in).
7. Switch from drive to platform lift function, and raise
the platform until the lower limit switch disengages,
the red indicator light on the level sensor will
illuminate with the alarm sounding, and further
lifting and driving is restricted.
8. Lower the platform to the stowed position, the alarm
will stop sounding, and the machine function limit is
cancelled.
9. Drive the machine off and remove the wooden
blocks.
10. With the machine in stowed position (outrigger
extended), place 2 wooden blocks near the two
wheels on the left or right side, then drive the
machine upon the wooden blocks. The wooden
block dimension (L×W×H) is 100×50×28mm
(4in×2in×1.1in).
11. Switch from drive to platform lift function, and raise
the platform until the lower limit switch disengages,
the red indicator light on the level sensor will
illuminate with the alarm sounding, and further
lifting and driving is restricted.
12. Lower the platform to the stowed position, the alarm
will stop sounding, and the machine function limit is
cancelled.
13. Drive the machine off and remove the wooden
blocks.
TESTING THE DRIVE SPEED
With the machine in stowed position:
1. Turn the Ground/Platform select switch on ground
controller to Platform.
2. Pull out the emergency stop buttons on ground and
platform controllers to ON position.
3. Press the engine start switch on platform controller.
4. Press the drive switch.
5. Hold the joystick enable switch and slowly deflect
forward the joystick to full stroke.
6. Press the drive high/low speed switch on platform
controller to select the high drive speed.
7. The max drive speed of the machine in stowed
position is 6.1±0.6Km/h (3.79±0.37mph), or the
drive time for 40m (131 ft) is 19～23s.
8. Hold the joystick enable switch and slowly deflect
forward the joystick to full stroke.
9. Press the drive high/low speed switch on platform
controller to select the low drive speed.
10. The max drive speed of the machine in stowed
position is 1.1±0.1Km/h (0.68±0.06mph), or the
drive time for 20m (65.6 ft) is 53～64s.
With the machine in operating position:
