MACHINE COMPONENTS
Table 2-1
1. Lanyard anchorage point 10. Safety Arm 19. Engine (inside the engine cover)
2. Fixed Platform 11. Lower Lift Cylinder 20. Transport tie-down position
3. Extended Platform 12. Outrigger 21. Chassis Assembly
4. Scissor Assembly 13. Non-steering Wheel 22. Oil cooler
5. Platform extension locking handle 14. Fuel Tank 23. Generator
6. Platform Entry Gate 15. Ladder 24. Maintenance-free battery
7. Fixed Platform Rail 16. Hydraulic Oil Tank 25. Ground Controller
8. Extended Platform Rail 17. Steer Wheel 26. Warning Light
9. Upper Lift Cylinder
18. Reducer 27.AC Power Socket
Machine positions
Stowed position:
The machine comes in stowed position when fully
retracted.
Non-operating position:
The machine remains in non-operating position when
the down limit switch does not disengage.
Operating/raised position:
The machine comes in operating/raised position
when the platform is raised until the down limit switch
disengages.
The platform height (from ground to platform floor) is
3±0.3m (9ft 10in±12in) when the down limit switch
disengages.
