Sirona Dental Systems GmbH 21 Distributor and Fuse Box
59 58 470 D 3370
D 3370.031.01.10.02
27
båÖäáëÜ
1. Screw on cover of fuse box tight.
2. Screw cable holder to distributor box with three screws.
3. Use ohmmeter to measure resistance between points
B and C. The value must be ∞.
ATTENTION
Due to the relevant EMC regulations, the distributor box and
all electrical parts must be isolated from all grounded points.
NOTE
i
If in addition a
• unit lamp,
• tray and/or
• Tray with SIVISION 3 monitor
have been ordered, they should be installed now (refer to
separate installation instructions).
21 Distributor and Fuse Box
1.
2.
3.
