35 Packing Position Sirona Dental Systems GmbH
59 58 470 D 3370
48 D 3370.031.01.10.02
To repack the chair (for example, for transportation to an
exhibition), move it to the position shown.
NOTE
i
Should the chair be moved after the water unit and the as-
sistant element are already dismantled, the short-circuit
plugs X8 and X90 on the connection box PC board CJ must
be reinserted (see chapter “Water Unit: Making Connec-
tions” on page 23 .
35 Packing Position
650 mm
300 mm
