Imaging
6-2
The scanning frequency of each probe is wide and changeable, and can be toggled
according to the diagnostic requirements. In unfrozen state, press
Freq key, to change
the frequency of the current probe. There are several frequencies available for selection.
In unfrozen state, press
T-Ball key to switch the touchpad function to control window.
Use the touchpad to select Probe Frequency in the control window and press Value
control key ( and )can also change the frequency of the current probe.
6.2.2 Selecting Exam Type
6.2.2.1 Function Description
For each kind of probe on different exam type (including application range and diagnostic
position), the system will conduct different initial settings based on its diverse
characteristics, so that the system can be in the best situation for a corresponding exam
type. These exam types provided by the system can be selected by the user and shown
on the bottom left of the screen.
The available exam types are shown in Table 6-1.
Table 6-1 Exam Types
Application Type Exam Types
Cardiology Adult, Adult Diff, Pediatric
Peripheral arteries Carotid, Peripheral arteries, Peripheral vein
Obstetrics 1
st
trimester, Basic OB, Complete OB, Fetal Echo, Mult Gest
Abdomen Liver, Gallbladder, Pancreas, Pediatric Abdomen
Gynecology Uterus, Ovary
Small Part Thyroid, Breast, Eyeball, Testes, Neonate
Urologic Kidney, Prostate
Orthopedics Orthopedics
Podiatry Podiatry
The system allows the user defining exam types by themselves; for each application type, the
total amount of the exam types defined by system and the exam types defined by the user
cannot exceed 10. While defining a new exam type, the system will automatically store the
current image control parameters to that exam type. Each exam type has a maximum length
