4. Assembly instructions
4.1. General information
Only qualified technical personnel may install,
operate, maintain, and repair the piston pump units
described in the assembly instructions. Qualified
technical personnel are persons who have been
trained, assigned and instructed by the operator of
the final product into which the described piston
pump units are incorporated. Such persons are
familiar with the relevant standards, rules, accident
prevention regulations, and operating conditions as
a result of their training, experience, and instruction.
They are qualified to carry out the required activities
and in doing so recognize and avoid potential
hazards.
The definition of qualified personnel and the
prohibition against employing non-qualified
personnel are laid down in DIN VDE 0105 and IEC
364.
Before assembling/setting up the piston pump unit
with reservoir, the packaging material and any
shipping braces (e.g., plugs) must be removed. Keep
the packaging material until any discrepancies have
been resolved.
Warning!
The product must not be tilted or dropped.
During all assembly work on commercial vehicles or
machinery, observe the local accident prevention
regulations as well as the applicable operating and
maintenance specifications.
4.2. Setup and attachment
The piston pump unit with reservoir should be
protected from humidity and vibration, and should
be mounted so that it is easily accessible, allowing all
further installation work to be done without
difficulty. The control screen, if present, must be
easily visible and reachable.
Ensure that there is sufficient air circulation to
prevent excessive heating of the piston pump unit
with reservoir. For the maximum permissible
ambient temperature, see "Technical data."
For the product-specific technical data on
a specific piston pump unit with reservoir,
see the relevant documentation. If no
documentation is available, you can
request the documentation directly from
SKF Lubrication Systems Germany GmbH .
The mounting position of the piston pump unit with
reservoir is vertical as shown in the
documentation.
Drill the assembly holes for wall-mounting the
piston pump unit as specified in Chapter 4.3,
"Connection dimensions."
