SKF KFA1 series User Manual

4. Assembly instructions Page 18
EN
4.4. Electrical connection
4.4.1. Electric motor connection
Piston pump units with reservoir are driven by
electric motors.
The general conditions for connections are given in
 Table 8.
Danger!
Electrical connections for the piston pump
unit with reservoir may only be established
by qualified and trained personnel
authorized to do so by the operator, and in
observance of the local conditions for
connections and local regulations (e.g.,
DIN, VDE). Incorrectly connected piston
pump units with reservoir can cause
considerable damage to property and
result in serious injury or death.
Danger!
The mains voltage (supply voltage) must
match the specifications on the  rating
plate of the piston pump unit. Check the
fuse protection of the electrical circuit. Use
only fuses with the prescribed amperage,
else bodily injury and property damage
may result.
Table 8 General conditions for connections
Design
Rated voltage
Typical power consumption
(load-dependent)
1)
Starting current
(approx. 20 ms) /
Inrush current
3.)
Back-up fuse
KFA1... / KFAS1...
Commercial vehicles
Mode S3 20%,
50 min
24 V DC
12 V DC
0.5 A
1.0 A
approx. 1.4 A
approx. 2.8 A
3.0 A
3.0 A
KFA1-M... / KFAS1-M...
Industrial
Mode S3 20%,
50 min
24 V DC
2)
0.5 A
approx. 1.4 A
3.0 A
KFA10 / KFA10-W
Industrial
Mode S3 5%,
100 min
230 V/50 Hz
230 V/60 Hz
115 V/50 Hz
115 V/60 Hz
0.77 A
0.54 A
1.54 A
1.08 A
-
-
-
-
3.0 A
3.0 A
3.0 A
3.0 A
KFAS10 / KFAS10-W
Industrial
Mode S3 20%,
50 min
230 V 50/60 Hz
115 V 50/60 Hz
0.40 A
0.65 A
40 A
20 A
2.5 A
2.5 A
2.5 A
2.5 A
1)
Typical value at an ambient temperature = 20 ℃ and operating pressure = 300 bar
2)
Protective measures to be taken for operation according to intended use:
"Functional Extra Low Voltage" / "Protective Extra Low Voltage" (PELV)
3)
only model design KFAS10-… with switch-mode power supply
