Page 17
EN
Warning!
When drilling the assembly holes, you
must be careful of any supply lines or
other units, as well as of other hazards
such as moving parts.
Maintain safety clearances and comply
with local regulations for assembly and
accident prevention.
Warning!
Do not tilt or drop the KFG (S) (C)
grease lubrication pump unit!
Install the pump units on the machine using
three M8 screws with a minimum length
of
20 mm.
Fastening material to be provided by the
customer:
Hexagon head screws (3x) acc. to
DIN933-M8x....-8.8
Washers (3x) acc. to DIN 125-B8.4-St
Warning!
The torque of the fastening screws
depends on the customer’s installation.
Make sure that torque is adequate
when installing the pump unit!
Assembly instructions
KFGS
KFG
KFGC
Shielded cables must be used in places where
electrical interference fields can distort signal
transmissions despite separate laying of cables.
consideration.
