Page 31
EN
4.5.3.3 Connectivity for counter operation
without system monitoring
Connector pin assignment in counter operation
PIN Code Assignment
1 31 - Supply voltage potential (0 V, GND)
2 15 +
   
  
  
  
  
4.5.3.4 Connectivity for counter operation
with system monitoring
Programming: cPA, tCO, COP = OFF
31 15
1
BN
KFGS...
F
2 3 4 5 6 7
X1
RD-BK
BU
PK
DK
SL2
2,4 W
31 15
1
BN
KFGS...
F
2 3 4 5 6 7
X1
RD-BK
BU
PK
DK
SL2
2,4 W
YE (+)
BK
ZS
Programming: cPA, tCO, COP = CS
One pulse is counted each time the
operating voltage is switched on when
the pushbutton is closed in counter
operation.
Control using machine pulses
(Counter mode = load-dependent lubrication))
The duration of the interval time is determined
by a pulse generator that sends pulses to the
control unit based on how long the vehicle has
been in use. The control unit counts the pulses
that are received and starts the pump after the
preset number of pulses.

value. Both the number of pulses that deter-
mine the interval time and the pump cycle

-
nected to the integrated pump control unit.

control level via indicator light SL2.
