600 Models
mmo2008-001-023_a
1. Fuse box
2. Cover tab
600 HO SDI Model
A29E10A
1
FUSE BOX
1. Cover tab
V800 Models
mmo2007-001-005_a
1. Fuse box
2. Cover tab
24) Front Grab Handles/
Front Bumper
To be used whenever front of snow-
mobile requires manual lifting.
WARNING
Donotattempttoliftthevehicle
by hand alone. Use appropriate
lifting device or have assistance
to share lifting stress in order to
avoid risk of strain injuries.
1
A03H0KA
TYPICAL
1. Front grab handles
CAUTION: Do not use skis to pull or
lift snowmobile.
V800 Models
CAUTION: Donotliftsnowmobile
by the front bumper.
25) Storage Compartment
WARNING
All storage compartments must be
properly latched and they must not
contain any heavy or breakable ob-
jects.
A storage compartment is provided
under seat. To open storage compart-
ment, lift seat latch, then tip seat over.
44
